Dimensions: L1 H1 & L1 H2 Panel Van
External dimensions (mm):
- Length: 5,080
- Width excl. mirrors / width incl. mirrors: 1,956/2,283
- Height: 1,971 (L1 H1) 2,495 (L1 H2)
- Wheelbase: 3,098
- Front overhang: 1,014
- Rear overhang: 968
Load compartment (mm):
- Length at floor level: 2,537
- Maximum width: 1,662
- Width between wheel arches: 1,268
- Length at 1 meter from the floor: 2,250
- Height: 1,387 (L1 H1) 1,898 (L1 H2)
- Loading sill: 552
- Load volume (m3): 5.8 (L1 H1) 7.75 (L1 H2)
Weights (kg):
- Vehicle weight (unladen): 1,867 (L1 H1) 1,980 (L1 H2)
- Payload with driver: 933 - 1,143 (L1 H1) 920 (L1 H2)
- GVW: 2,800 - 3,010 (L1 H1) 2,900 (L2 H2)
